High precision servo drive roll slitting machine using the computer and the United Kingdom, Germany advanced technology, the computer control system of the international top brands - Germany Original Bryant (KEB) and the Japan servo motor AC drive, belt use Bonita (NITTA ), pneumatic vibrator with Swiss bandit d'Ivoire (FINDEVA), Schneider and Omron electrical system, so that cutting is faster and stable; German precision bearings and cutting knife, cut off the high precision; touch computer interface control, operation simple; construct a reasonable anti-music stands, to ensure smooth paper, paper and printing industry is commonly used in paper processing machinery.
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Main technical parameters:
|
Mode
|
ZBGM-1400/1700/1900
|
Mode
|
ZBGM-1400/1700/1900
|
|
Cutting form
|
Cut back on the knife, the knife fixed
|
Maximum cutting speed m
|
350m/min
|
|
Paper Range
|
60-550g
|
Cutting length
|
450~1450mm
|
|
Cutting precision
|
Cutting Length
1000mm:+/-0.5mm |
Maximum height of heap cardboard
|
1300mm
|
|
Maximum cutting speed
|
350cuts/min
|
Maximum roll diameter
|
1800mm(71")Max
|
|
Machine weight
|
13,000kgs/15,000kgs/17,000kgs
|
Maximum roll width
|
1400mm/1700mm/1900mm
|
|
Design Po
|
380v/220v * 50Hz
|
Number of profile pieces of paper
|
2（2 sheet）
|
|
|
|
Air supply requirements
|
0.8Mpa
|
