ZBCM-1400 1700 1900 servo drive roll cutting machine high-precision computer

Hits：
ZBCM-1400 1700 1900 servo drive roll cutting machine high-precision computer

ZBCM-1400/1700/1900 high-precision servo drive roll slitter is a computer company uses advanced technology to Germany and the United Kingdom developed a cutting machine, the computer control system of the international top brands - Germany Original Bryant (KEB) and AC servo motor drive, the conveyor belt of Japan Bonita (NITTA), pneumatic vibrator use 瑞士菲迪瓦 (FINDEVA), Schneider and Omron electrical system, so that the cutting is faster and stable; German precision bearings and cutting knife, cut off the high precision; touch computer interface control, easy to operate; construct a reasonable anti-music stands, to ensure smooth paper, paper and printing industry is commonly used in product processing machinery.

Main technical parameters:

Model
 		 ZBCM-1400/1700/1900
Model
 ZBCM-1400/1700/1900
Cutting form

Cut back on the knife, the knife fixed

Maximum cutting speed m
 250m/min
Paper Range

 		  60-550g
Cutting length
 450~1450mm
Cutting precision


Cutting Length 1000mm: + /-0.5mm

Maximum roll diameter
  1650mm(65")Max
Maximum cutting speed

 		  250cuts/min  最大卷筒纸张幅  1400mm(65")Max
Machine weight
  11,000kgs/13,000kgs/15,000kgs    1700mm(67")Max
       1900mm(75")Max
