ZBCM-1400 1700 1900A high-precision servo drive roll cutting machine computer

Hits：
ZBCM-1400 1700 1900A high-precision servo drive roll cutting machine computer

ZBCM-1400/1700/1900 high-precision servo drive roll slitter is a computer company uses advanced technology to Germany and the United Kingdom developed a cutting machine, the computer control system of the international top brands - Germany Original Bryant (KEB) and AC servo motor drive, the conveyor belt of Japan Bonita (NITTA), pneumatic vibrator use 瑞士菲迪瓦 (FINDEVA), Schneider and Omron electrical system, so that the cutting is faster and stable; German precision bearings and cutting knife, cut off the high precision; touch computer interface control, easy to operate; construct a reasonable anti-music stands, to ensure smooth paper, paper and printing industry is commonly used in product processing machinery.

Main technical parameters:

Model
 ZBCM-1400/1700/1900 Model ZBCM-1400/1700/1900
Cutting form
  Cut back on the knife, the knife fixed
Maximum cutting speed m
 300m/min
Paper Range
  60-550g

Cutting length
 450~1450mm
Cutting precision

Cutting Length
1000mm:+/-0.5mm
Maximum roll diameter
  1650mm(65")Max
Maximum cutting speed
  300cuts/min
Maximum roll width
  1400mm(65")Max
Machine weight
  11,000kgs/13,000kgs/15,000kgs    1700mm(67")Max
       1900mm(75")Max
