Film Blowing Machine
Your location：Home >> Film Blowing Machine
Optional equipment:
1、Auto Liader 2、Air Compressor 3、Special Die 4、Die Rotary Device 5、Bouble Sides Winder
Main Technical Variables:
| Model | 600mm | 800mm | 1000mm |
| Applied mterials | LDPE.HDPE.LLDPE | LDPE.HDPE.LLDPE | LDPE.HDPE.LLDPE |
| Screw dia | 50mm | 55m | 65mm |
| Screw L/D ratio | 28:1 | 28:1 | 28:1 |
| Blow film motor power | 11Kw | 15Kw | 18.5Kw |
| Max extruded quantity | 35kg/h | 50Kg/h | 65Kg/h |
| Film head dia | φ60、φ 100 | φ80、φ150 | φ100、φ200 |
| Blow film width | 600mm | 800mm | 1000mm |
| Blow film thickness | 0.01-0.10mm | 0.01-0.10mm | 0.01-0.10mm |
| Length range of printing | 191-1200mm | 191-1200mm | 191-1200mm |
| Printing width | 600mm | 800mm | 1000mm |
| Total power | 28Kw | 32Kw | 40kw |
| Weight of machinery | 3.5T | 4T | 5T |
| Dimensions of machinery | 6000 x 2400 x 4000mm | 6200 x 2600 x 4300mm | 6400 x 2800 x 4800mm |
