Uses:
This machine is suitable for BOPP, PET, CPP, PVC, aluminum foil, paper and other material volume cut.
Three motor vector control system for: the machine adopts imported PLC centralized control. Traction and rolling to achieve constant speed control, put the volume constant tension control. PLC automatic calculation of material rolling down the diameter of material empty converter so that the upper and lower control precision electrical slip correct air shaft torque, combined with the taper to achieve the taper up and down the winding tension control; the use of sophisticated valve control up and down the winding pressure roll to get the desired pressure. The use of precision air shaft can slip the slip to achieve the desired effect, solve the two-axis cutting down the problem of uneven thickness. Put the rolls of the same diameter PLC automatic calculation, automatic unwinding motor torque control to achieve constant tension unwinding. Winding using slip air shaft, precision valve control air pressure and the rolling roller speed control with advanced solutions cut product does not stretch, deformation, cutting more smooth and so on.
Features:
1, no-unwinding shaft (air up the shaft material), with screw clamp loading, electric elastic; achieved using hydraulic lift to move the rack's operation.
2, each guide roller is affixed anti-slip tape.
3, winding the use of precision slip air shaft; pressure arm support, pneumatic positioning; with unloading rack.
4, correcting the executing agency for the high-speed static correcting, mobile travel 120mm.
5, cut with round cutter knife cutting the peace;
6, the system has a meter, roll-off material diameter operation and protection, to achieve given the number of meters, set the volume diameter cutting;
7, the system has improved mechanical, electrical, pneumatic design, and to take comprehensive security measures.
Technical parameters:
| Parameters of the project |
Parameter index |
| Material Width: |
1300mm |
| Paper core diameter: |
ф76mm |
| Finished Width: |
30-1300mm |
| Weight: (approx.) |
4200kg |
| Material diameter: |
ф600mm |
| Cutting speed: |
<=300m/min |
| Cutting precision: |
0.5mm |
|
Overall dimensions:
|
1880×2700×1580(
Under the rack
1550mm) |
