Uses:
This machine is suitable for BOPP, PET, PVC, PE and Paper etc with good printing performance of rolling material for multicolor continuous printing
Features:
①, winding and rewinding are rolling duplex institutions, non-stop grafting material.
②, host vector variable frequency motor speed, the whole three motor constant tension control system.
③, every computer flashed system by an independent microprocessor control unit can adjust the flashed deviation quickly and accurately.
④, double-eye detection and improve the detection and adjustment of machine speed.
⑤, unwinding, pulling out of material with automatic tension controller and magnetic powder brake control.
⑥, rolling, rolling traction motor and inverter using vector control motor torque.
⑦, printing press rollers, the feed roller traction, rewinding traction roller, the use of pneumatic control.
⑧, Pneumatic backpressure moving scraper. Air chucks.
⑨, ink circulation system.
⑩, can elect different computer flashed boundary and stationary checking.
Main technical parameters:
| Model |
ASY600 | ASY800 | ASY1000 | ASY1200 |
| Plate diameter |
100-320mm | 100-320mm | 100-320mm | 100-320mm |
| Maximum printing width |
600mm | 800mm | 1000mm | 1200mm |
| Diameter of unwinding and rewinding |
600mm | 600mm | 600mm | 600mm |
| Printing speed |
90m/min | 90m/min | 90m/min | 90m/min |
| Overlay accuracy |
≤0.15mm | ≤0.15mm | ≤0.15mm | ≤0.15mm |
| Drying methods |
|
Electric heating
|
Electric heating
|
Electric heating
|
| Machine power |
76kw | 78kw | 82kw | 86kw |
| Weight |
14000KG | 15000KG | 16000KG | 17000KG |
|
Dimensions
|
132*250*250m | 132*270*250m | 132*290*250m | 132*310*250m |
