Bag Making Machine
Your location：Home >> Bag Making Machine
Usage and features:
This machine is applied to hot cutting and bag-making with the materials like BOPP ,PP, PE and POF. It is widely used in the daily packing, featuring quickness, beautiful and firm sealed sides, ease of adjustment and maintenance.
Performance and allocations:
1.Name brand frequency speed converter for the major motor;
2. LCD computer, coordinating microsound disaggr-egated classification step motor drive
3. Pneumatic/mechanic two-purpose punch;
4. Intellectual thermocontroller
5. Strong static electric eliminator;
6. Double-sided heat sealing blades (with state patent No. ZL02245698.8)
Main technical parameters:
| Model | 700mm | 800mm | 1000mm |
| Power | 220/380V | 220/380V | 220/380V |
| Total power | 4kw | 5.5kw | 6kw |
| Average power | 2kw | 3kw | 5kw |
| Bag-making W | 60-690mm | 150-750mm | 100-950mm |
| Bag-making L | 45-999mm | 60-600mm | 60-1999mm |
| Bag-making Speed | 30-200P/min | 40-200P/min | 20-160P/min |
| Weight | 730kg | 0.01-0.06mm | 1250kg |
| Length of machine | 3300mm | 1200kg | 4050mm |
| Width of machine | 1100mm | 7400mm | 1390mm |
| Height of machine | 1275mm | 1900mm | 1850mm |
